Mascar 5100 Auto Dual Wrapper
Professional dual-dispenser trailed turntable-wrapper with pickup and carry bale fork with full function bale monitor and push-button electro-hydraulic control. ![]() Photograph for illustration purposes - standard specifications may not match those shown. |
||
FEATURES OF THE 5100 AUTO DUAL WRAPPER |
||
CHASSIS |
||
![]() |
|
|
![]() |
|
|
![]() |
|
|
![]() |
|
|
FILM DISPENSERS |
||
![]() |
|
|
![]() |
|
|
![]() |
|
|
![]() |
|
|
WRAPPING |
||
![]() |
|
|
![]() |
|
|
![]() |
|
|
![]() |
|
|
![]() |
|
|
GENERAL |
||
![]() |
|
|
![]() |
|
|
APPLICATIONS |
||
|
![]() |
![]() |
Cradle holds bale on discharge |
Vertical bale discharge |
![]() |
|
Two bale capacity - Wrap and pickup/carry the second bale |
|
SPECIFICATIONS |
5100 Auto | |
BALER | |
Bale width (cm) | 120 |
Bale diameter (cm) | 120-160 |
Max bale weight (kg) | 1300 |
Max speed cradle rotation (rpm) | 30 |
FILM | |
Film cutting | Automatic |
Film release | Automatic |
Reel height (mm) | 750 |
Max reel diameter (mm) | 300 |
Film thickness (mm) | 0.025 – 0.035 |
Stretching (%) | 52 – 61 – 70 - 79 |
ELECTRIC SUPPLY | 12 V |
HYDRAULIC SYSTEM | |
Connection | 1 Single-acting, 1 free return |
Recommended/max oil capacity (l/min) | 20 / 30 |
Min/max oil inlet pressure (bar) | 150 / 180 |
Power requirements (kW) | 22 |
DIMENSIONS AND WEIGHTS | |
Tyres | 340/55-16 |
Min/max towing eye height (cm) | 37 – 107 |
Max weight on towing eye (kg) | 200 |
Towing eye measurements (mm) | Øi 35 – Øe 95 rotatable |
Net weight (full optional) (kg) | 1780 |
Max lenght (cm) | 535 |
Width (cm) | 243 |
Road (cm) | 209 |
Max height (cm) | 298 |
Rollers height (cm) | 123 |
Min ground clearance (cm) | 23 |
BROCHUREClick this link to download a brochure. Please note that Australian specifications may vary to those shown on the manufacturer's brochure and website. |
|
Disclaimer: Specifications and features described on the website are subject to change without notice. All care has been taken to present accurate information, however, the company is not liable for unintended errors or omissions. |
